Redefining The Scope of Plaque Modification in Calcified Lesions

Overview

OPN NC is a unique Swiss made CE Marked Plaque Modification Device designed to perform in all complex lesions at Ultra-High Pressures. OPN NC utilizes Ultra-High Pressures to cause Calcium fracture or oppose Calcium to arterial wall.OPN NC is designed with a dual layer technology to withstand Ultra-High Pressures which leads to uniform expansion even at pressures as high as 45 Bars.

Resources
Product Brochure

DESIGNED TO PERFORM IN ALL COMPLEX LESION SUBSETS

Linear Compliance and Uniform Expansion

  • OPN NC grows less than 10 % until the Rated Burst Pressure of 35 Bars
  • OPN NC has a Uniform Expansion at pressure of 45 Bars as well, with no Dog Boning seen
  • OPN NC causes minimal perforations and no edge dissections

INDICATIONS FOR USE

  • For Plaque Modification in moderate to severely calcified lesions
  • In combination with Rotablation for large vessel diameters
  • Successful treatment of ISRs-
  • DES Under Expansion due to severe calcification
  • Neo atherosclerosis with Calcification
  • Two layers of DES in combination with DEB
  • ISR CTO
  • 1.5 mm smallest non compliant balloon for severely calcified coronary arteries

TIPS AND TRICKS: REMEMBER WHILE USING OPN NC

  • Avoid Polymer Sleeve wires and Use Extra Support Guidewires for accessing the lesions.
  • For Pre Dilatation /treatment of DES ISR use 0.5 mm lesser diameter balloon than the Reference Vessel Diameter.
  • For Post Dilatation 1:1 Balloon to Vessel ratio is recommended.
  • Slow increment of pressures ( above 20 atm, increase progressively , approx. 5 atm/ 10-20 sec) for adequate luminal gain.
  • Allow Balloon “to work/ deploy”(slight decrease in pressure due to expansion of the balloon) before increasing the pressure.
  • Remember to De-air the Balloon and choose the correct size for optimal results at Ultra High Pressures.

OPN ID (Ultra High Pressure Inflation Device)

*OPN NC should be used with OPN ID (Swiss made Inflation Device) with a working limit of 55 ATM for optimum utilisation of the device
  • Pressure Range 55 ATM
  • Manometer Resolution 5 ATM
